Using Julia

Overview

Quarto supports executable Julia code blocks within markdown. This allows you to create fully reproducible documents and reports—the Julia code required to produce your output is part of the document itself, and is automatically re-run whenever the document is rendered.

Quarto has two available engines for executing Julia code. The older one is using the IJulia Jupyter kernel and depends on Python to run. The newer engine is using the QuartoNotebookRunner.jl package to render notebooks and does not have any additional dependencies beyond a Julia installation.

Using the jupyter engine

Below we’ll describe how to install IJulia and related requirements but first we’ll cover the basics of creating and rendering documents with Julia code blocks.

Code Blocks

Code blocks that use braces around the language name (e.g. ```{julia}) are executable, and will be run by Quarto during render. Here is a simple example:

---
title: "Plots Demo"
author: "Norah Jones"
date: "5/22/2021"
format:
  html:
    code-fold: true
jupyter: julia-1.8
---

### Parametric Plots

Plot function pair (x(u), y(u)).
See @fig-parametric for an example.

```{julia}
#| label: fig-parametric
#| fig-cap: "Parametric Plots"

using Plots

plot(sin,
     x->sin(2x),
     0,
     2π,
     leg=false,
     fill=(0,:lavender))
```

You’ll note that there are some special comments at the top of the code block. These are cell level options that make the figure cross-referenceable.

This document would result in the following rendered output:

Example Plots Demo output with title, author, date published and main section on Parametric plots which contains text, a toggleable code field, and the output of the plot, with the caption Figure 1 Parametric Plots.

You can produce a wide variety of output types from executable code blocks, including plots, tabular output from data frames, and plain text output (e.g. printing the results of statistical summaries).

There are many options which control the behavior of code execution and output, you can read more about them in the article on Execution Options.

In addition to code blocks which interrupt the flow of markdown, you can also include code inline. Read more about inline code in the Inline Code article.

Multiple Outputs

By default Julia cells will automatically print the value of their last statement (as with the example above where the call to plot() resulted in plot output). If you want to display multiple plots (or other types of output) from a single cell you should call the display() function explicitly. For example, here we output two plots side-by-side with sub-captions:

```{julia}
#| label: fig-plots
#| fig-cap: "Multiple Plots"
#| fig-subcap:
#|   - "Plot 1"
#|   - "Plot 2"
#| layout-ncol: 2

using Plots
display(plot(sin, x -> sin(2x), 0, 2))
display(plot(x -> sin(4x), y -> sin(5y), 0, 2))
```

Rendering

Quarto will automatically run computations in any markdown document that contains executable code blocks. For example, the example shown above might be rendered to various formats with:

Terminal
quarto render document.qmd # all formats
quarto render document.qmd --to pdf
quarto render document.qmd --to docx

The render command will render all formats listed in the document YAML. If no formats are specified, then it will render to HTML. You can also provide the --to argument to target a specific format.

Quarto can also render any Jupyter notebook (.ipynb):

Terminal
quarto render document.ipynb

Note that the target file (in this case document.qmd) should always be the very first command line argument.

Note that when rendering an .ipynb Quarto will not execute the cells within the notebook by default (the presumption being that you already executed them while editing the notebook). If you want to execute the cells you can pass the --execute flag to render:

Terminal
quarto render notebook.ipynb --execute

Installation

In order to render documents with embedded Julia code you’ll need to install the following components:

  1. IJulia
  2. Revise.jl
  3. Optionally, Jupyter Cache

We’ll cover each of these in turn below.

IJulia

IJulia is a Julia-language execution kernel for Jupyter. You can install IJulia from within the Julia REPL as follows:

using Pkg
Pkg.add("IJulia")
using IJulia
notebook()

The first time you run notebook(), it will prompt you for whether it should install Jupyter. Hit enter to have it use the Conda.jl package to install a minimal Python+Jupyter distribution (via Miniconda) that is private to Julia (not in your PATH). On Linux, it defaults to looking for jupyter in your PATH first, and only asks to installs the Conda Jupyter if that fails.

If you choose not to use Conda.jl to install Python and Jupyter you will need to make sure that you have another installation of it on your system (see the section on Installing Jupyter if you need help with this).

Revise.jl

In addition to IJulia, you’ll want to install Revise.jl and configure it for use with IJulia. Revise.jl is a library that helps you keep your Julia sessions running longer, reducing the need to restart when you make changes to code.

Quarto maintains a persistent kernel daemon for each document to mitigate Jupyter start up time during iterative work. Revise.jl will make this persistent process robust in the face of package updates, git branch checkouts, etc. Install Revise.jl with:

using Pkg
Pkg.add("Revise")

To configure Revise to launch automatically within IJulia, create a .julia/config/startup_ijulia.jl file with the contents:

try
  @eval using Revise
catch e
  @warn "Revise init" exception=(e, catch_backtrace())
end

You can learn more about Revise.jl at https://timholy.github.io/Revise.jl/stable.

Jupyter Cache

Jupyter Cache enables you to cache all of the cell outputs for a notebook. If any of the cells in the notebook change then all of the cells will be re-executed.

If you are using the integrated version of Jupyter installed by IJulia.notebook(), then you will need to add jupyter-cache to the Python environment managed by IJulia. You can do that as follows:

using Conda
Conda.add("jupyter-cache")

Alternatively, if you are using Jupyter from within any other version of Python not managed by IJulia, see the instructions below on Installing Jupyter for details on installing jupyter cache,

Workflow

You can author Quarto documents that include Julia code using any text or notebook editor. No matter what editing tool you use, you’ll always run quarto preview first to setup a live preview of changes in your document. Live preview is available for both HTML and PDF output. For example:

Terminal
# preview as html
quarto preview document.qmd

# preview as pdf
quarto preview document.qmd --to pdf

# preview a jupyter notebook
quarto preview document.ipynb

Note that when rendering an .ipynb Quarto will not execute the cells within the notebook by default (the presumption being that you have already executed them while editing the notebook). If you want to execute the cells you can pass the --execute flag to render:

Terminal
quarto render notebook.ipynb --execute

You can also specify this behavior within the notebook’s YAML front matter:

---
title: "My Notebook"
execute:
  enabled: true
---

Embed Notebooks

In addition to including executable Julia code chunks in a Quarto document, you can also embed cells from an external Jupyter Notebook (.ipynb). See Embedding Jupyter Notebook Cells for more details.

VS Code

The Quarto Extension for VS Code provides a variety of tools for working with .qmd files in VS Code. The extension integrates directly with the Julia Extension to provide the following Julia-specific capabilities:

  1. Code completion
  2. Cell execution
  3. Contextual help

Screen shot of VS Code with quarto document containing Julia code on the left, the output of a plot from the Julia code on the right, and the Quarto Help pane at the bottom.

You can install the VS Code extension by searching for ‘quarto’ in the extensions panel or from the extension marketplace.

You can also use the VS Code notebook editor to create Julia notebooks that you will render with Quarto. The next section discusses using notebooks with Quarto in the context of Jupyter Lab, but the same concepts apply to VS Code.

Jupyter Lab

We could convert the simple document.qmd we used as an example above to a Jupyter notebook using the quarto convert command. For example:

Terminal
quarto convert document.qmd

If we open this notebook in Jupyter Lab and execute the cells, here is what we see:

Side-by-side preview of notebook on the left and live preview in the browser on the right.

Note that there are three different types of cell here:

  1. The YAML document options at the top are in a Raw cell.
  2. The heading and explanation are in a Markdown cell.
  3. The Julia code and its output are in a Code cell.

When working in a Jupyter notebook, you can use quarto preview to provide a live preview of your rendered document:

Terminal
quarto preview document.ipynb

The preview will be updated every time you save the notebook in Jupyter Lab.

Caching

Jupyter Cache enables you to cache all of the cell outputs for a notebook. If any of the cells in the notebook change then all of the cells will be re-executed.

To use Jupyter Cache you’ll want to first install the jupyter-cache package:

Platform Command
Mac/Linux
Terminal
python3 -m pip install jupyter-cache
Windows
Terminal
py -m pip install jupyter-cache

To enable the cache for a document, add the cache option. For example:

---
title: "My Document"
format: html
execute:
  cache: true
---

You can also specify caching at the project level. For example, within a project file:

project:
  type: website

format:
  html:
    theme: united

execute:
  cache: true

Note that changes within a document that aren’t within code cells (e.g. markdown narrative) do not invalidate the document cache. This makes caching a very convenient option when you are working exclusively on the prose part of a document.

Jupyter Cache include a jcache command line utility that you can use to analyze and manage the notebook cache. See the Jupyter Cache documentation for additional details.

Rendering

You can use quarto render command line options to control caching behavior without changing the document’s code. Use options to force the use of caching on all chunks, disable the use of caching on all chunks (even if it’s specified in options), or to force a refresh of the cache even if it has not been invalidated:

Terminal
# use a cache (even if not enabled in options)
quarto render example.qmd --cache

# don't use a cache (even if enabled in options)
quarto render example.qmd --no-cache

# use a cache and force a refresh
quarto render example.qmd --cache-refresh

Alternatives

If you are using caching to mitigate long render-times, there are some alternatives you should consider alongside caching.

Disabling Execution

If you are working exclusively with prose / markdown, you may want to disable execution entirely. Do this by specifying the enabled: false execute option For example:

---
title: "My Document"
format: html
execute:
  enabled: false
---

Note that if you are authoring using Jupyter .ipynb notebooks (as opposed to plain-text .qmd files) then this is already the default behavior: no execution occurs when you call quarto render (rather, execution occurs as you work within the notebook).

Freezing Execution

If you are working within a project and your main concern is the cumulative impact of rendering many documents at once, consider using the freeze option.

You can use the freeze option to denote that computational documents should never be re-rendered during a global project render, or alternatively only be re-rendered when their source file changes:

execute:
  freeze: true  # never re-render during project render
execute:
  freeze: auto  # re-render only when source changes

Note that freeze controls whether execution occurs during global project renders. If you do an incremental render of either a single document or a project sub-directory then code is always executed. For example:

Terminal
# render single document (always executes code)
quarto render document.qmd

# render project subdirectory (always executes code)
quarto render articles

Learn more about using freeze with projects in the article on managing project execution.

Kernel Selection

You’ll note in our first example that we specified the use of the julia-1.7 kernel explicitly in our document options (shortened for brevity):

---
title: "StatsPlots Demo"
jupyter: julia-1.7
---

If no jupyter kernel is explicitly specified, then Quarto will attempt to automatically discover a kernel on the system that supports Julia.

You can discover the available Jupyter kernels on your system using the quarto check command:

Terminal
quarto check jupyter

Kernel Daemon

To mitigate the start-up time for the Jupyter kernel Quarto keeps a daemon with a running Jupyter kernel alive for each document. This enables subsequent renders to proceed immediately without having to wait for kernel start-up.

The purpose of the daemon is to make render more responsive during interactive sessions. Accordingly, no daemon is created when documents are rendered without an active tty or when they are part of a batch rendering (e.g. in a Quarto Project).

Note that Quarto does not use a daemon by default on Windows (as some Windows systems will not allow the socket connection required by the daemon).

You can customize this behavior using the daemon execution option. Set it to false to prevent the use of a daemon, or set it to a value (in seconds) to determine the period after which the daemon will timeout (the default is 300 seconds). For example:

execute:
  daemon: false
execute:
  daemon: 60

Note that if you want to use a daemon on Windows you need to enable it explicitly:

execute:
  daemon: true

Command Line

You can also control use of the Jupyter daemon using the following command line options:

Terminal
# use a daemon w/ default timeout (300 sec)
quarto render document.qmd --execute-daemon

# use a daemon w/ an explicit timeout
quarto render document.qmd --execute-daemon 60

# prevent use of a daemon
quarto render document.qmd --no-execute-daemon

You can also force an existing daemon to restart using the --execute-daemon-restart command line flag:

Terminal
quarto render document.qmd --execute-daemon-restart

This might be useful if you suspect that the re-use of notebook sessions is causing an error.

Finally, you can print extended debugging information about daemon usage (startup, shutdown, connections, etc.) using the --execute-debug flag:

Terminal
quarto render document.qmd --execute-debug

Installing Jupyter

You can rely on the minimal version of Python and Jupyter that is installed automatically by IJulia, or you can choose to install Python and Jupyter separately. If you need to install another version of Jupyter this section describes how.

If you don’t yet have Python 3 on your system, we recommend you install a version using the standard installer from https://www.python.org/downloads/.

If you are in a fresh Python 3 environment, installing the jupyter package will provide everything required to execute Jupyter kernels with Quarto:

Pkg. Manager Command
Pip
(Mac/Linux)
Terminal
python3 -m pip install jupyter
Pip
(Windows)
Terminal
py -m pip install jupyter
Conda
Terminal
conda install jupyter

You can verify that Quarto is configured correctly for Jupyter with:

Terminal
quarto check jupyter

Quarto will select a version of Python using the Python Launcher on Windows or system PATH on MacOS and Linux. You can override the version of Python used by Quarto by setting the QUARTO_PYTHON environment variable.

Jupyter Cache

Jupyter Cache enables you to cache all of the cell outputs for a notebook. If any of the cells in the notebook change then all of the cells will be re-executed.

To use Jupyter Cache you’ll want to first install the jupyter-cache package:

Platform Command
Mac/Linux
Terminal
python3 -m pip install jupyter-cache
Windows
Terminal
py -m pip install jupyter-cache
Conda
Terminal
conda install jupyter-cache

To enable the cache for a document, add the cache option. For example:

Using the julia engine

Installation

The julia engine uses the QuartoNotebookRunner.jl package to render notebooks. When you first attempt to render a notebook with the julia engine, Quarto will automatically install this package into a private environment that is owned by Quarto. This means you don’t have to install anything in your global Julia environment for Quarto to work and Quarto will not interfere with any other Julia environments on your system. Quarto will use the julia binary on your PATH by default, but you can override this using the QUARTO_JULIA environment variable.

Using custom versions of QuartoNotebookRunner

In special circumstances, you may not want to use the specific QuartoNotebookRunner version that Quarto installs for you. For example, you might be developing QuartoNotebookRunner itself, or you need to use a fork or an unreleased version with a bugfix. In this case, set the environment variable QUARTO_JULIA_PROJECT to a directory of a julia environment that has QuartoNotebookRunner installed.

As an example, you could install the main branch of QuartoNotebookRunner into the directory /some/dir by executing ]activate /some/dir in a julia REPL followed by ]add QuartoNotebookRunner#main. As long as there is no server currently running, running a command like QUARTO_JULIA_PROJECT=/some/dir quarto render some_notebook.qmd in your terminal will ensure the server process is started using the custom QuartoNotebookRunner. You can also set quarto’s --execute-debug flag and check the output to verify that the custom environment is being used.

Rendering notebooks

To use the julia engine, you have to specify it in your frontmatter:

---
title: "A julia engine notebook"
engine: julia
---

```{julia}
1 + 2
```

Rendering a notebook will start a persistent server process if it hasn’t already started. This server process first loads QuartoNotebookRunner from Quarto’s private environment. QuartoNotebookRunner then spins up a separate Julia worker process for each notebook you want to render.

Notebook environments

By default, QuartoNotebookRunner will use the --project=@. flag when starting a worker. This makes Julia search for an environment (a Project.toml or JuliaProject.toml file) starting in the directory where the quarto notebook is stored and walking up the directory tree from there.

For example, for a file /some/dir/notebook.qmd it will look at /some/dir/[Julia]Project.toml, /some/[Julia]Project.toml and so on. You could use this behavior to let all notebooks in a quarto project share the same Julia environment, by placing it at the project’s top-level directory.

If no environment has previously been set up in any of these directories, the worker process will start with an empty environment. This means that only Julia’s standard library packages will be available for use in the notebook.

Note

Creating a separate environment for each notebook or each set of closely related notebooks is considered best practice. If too many different notebooks share the same environment (for example the main shared environment that Julia usually loads by default), you’re likely to break some of them unintentionally whenever you make a change to the environment.

You can create a Julia environment in multiple ways, for more information have a look at the official documentation. One simple option for adding packages to the default environment of a new quarto notebook is to add some Pkg installation commands to the notebook and run it once. Afterwards, those commands can be deleted and a Project.toml and Manifest.toml file representing the environment should be present in the notebook’s directory.

---
engine: julia
---

```{julia}
using Pkg
Pkg.add("DataFrames")
```

Another option is to start julia in a terminal which loads the REPL, and to press ] to switch to the Pkg REPL mode. In this mode, you can first activate the desired environment by running activate /some/dir and then, for example, install the DataFrames package with the command add DataFrames.

If you do not want to use the notebook’s directory as the environment, you may specify a different directory via the --project flag in the exeflags frontmatter setting:

---
engine: julia
julia:
  exeflags: ["--project=/some/other/dir"]
---

Worker process reuse

An idle worker process will be kept alive for 5 minutes by default, this can be changed by passing the desired number of seconds to the daemon key:

---
title: "A julia notebook with ten minutes timeout"
engine: julia
execute:
  daemon: 600
---

Each re-render of a notebook will reuse the worker process with all dependencies already loaded, which reduces latency. As far as technically possible, QuartoNotebookRunner.jl will release resources from previous runs to the garbage collector. In each run, the code is evaluated into a fresh module so you cannot run into conflicts with variables defined in previous runs. Note, however, that certain state changes like modifications to package runtime settings or the removal or addition of function methods will persist across runs. If necessary, you can use the --execute-daemon-restart flag to force a restart of a notebook’s worker process.

You can also disable the daemon which will use a new process for each render (with higher latency due to package reloads):

execute:
  daemon: false

The server process itself will time out after five minutes if no more worker processes exist.

Engine options

Engine options can be passed under the julia top-level key:

---
title: "A julia engine notebook"
engine: julia
julia:
  key: value
---

The currently available options are:

  • exeflags: An array of strings which are appended to the julia command that starts the worker process. For example, a notebook is run with --project=@. by default (the environment in the directory where the notebook is stored) but this could be overridden by setting exeflags: ["--project=/some/directory/"].
  • env: An array of strings where each string specifies one environment variable that is passed to the worker process. For example, env: ["SOMEVAR=SOMEVALUE"].

Limitations

Currently, the engine: julia option must be specified in each .qmd file. Setting the engine project-wide via _quarto.yml is not yet supported.
